diesel engine(drive power for generator,pump,agricultural machinery,construction machinery))

2

Model
YM170F /FE
YM178F/FE
YM186F/FE
YM186FA/FAE
Type
Single cylinder,vertical,4-stroke,air cooled
Combustion System
Direct Injection
Bore X Stroke(mm)
70x55
78x62
86x70
86x72
Displacement(cc)
211
296
406
418
Engine Speed(rmp)
3000
3600
3000
3600
3000
3600
3000
3600
1h Output kw (hp)
2.8(3.8)
3.1(4.2)
4.2(5.7)
5.1(7)
6.5(9)
7.3(10)
7.3(10)
8(11)
12h Output kw (hp)
2.5(3.4)
2.8(3.8)
3.8(5.2)
4.4(6)
6(8.2)
6.5(9)
6.5(9)
7.3(10)
Starting Mode
Hand Starting(recoil) or Electric Starting
PTO Shaft
Crankshaft or camshaft (Camshaft PTO rpm is 1/2)
Fuel Tank Capacity(L)
2.5
3.5
5.5
5.5
Lub. Oil Capacity(L)
0.75
1.1
1.65
1.65
Fuel consumption(g/kwh)
280
288
276
285
275
282
275
282
Dry weight(kg)
27/31
33/38
48/53
48/53
Dimension(mm)
450x370x470
480x440x520
530x510x575
530x510x575

YM170F/YM178F/YM86F/YM186FA start method are handle start.

YM170FE/YM178FE/YM186FE/YM186FAE start method are electric start.
